FR Copper mesh PTFE soft belt bearing

FR Copper mesh PTFE soft belt bearing
FR Copper mesh PTFE soft belt bearing
FR Copper mesh PTFE soft belt bearing
FR Copper mesh PTFE soft belt bearing
FR
FR
FR
FR
FR

Structural properties and uses

The FR soft belt material is based on bronze wire mesh, and is made by sintering related reinforced friction-reducing materials such as PTFE on the surface. This material construction makes the product lighter and easier to install. The product has a lower coefficient of friction and better wear properties. Because of its particularly good softness, it can be processed into an isolation film between steel and steel metal to achieve an ideal state of no gap, no noise, no oil lubrication, no maintenance, and no pollution.

Metal bearing capacity thickness self-moisturizing
Tin bronze 0.48±0.02 PTFE body and associated friction reducing materials
brass 0.48±0.02
Stainless steel 0.48±0.02
  • Automobile door and window hinges, textile machinery, joint bearings, chemical industry, food industry, valve control mechanism, office machinery, instrumentation, etc., light load and low speed but need self-lubricating different occasions.
